Flintec MCS-64 CANbus User Manual

Page 23

Manual MCS-64 Page 23

Index

Sub-
index

Name

Type

Attri-
bute

Default-value

Meaning

2900 -
293F

for
LDM
0..63

0
1
2
3
4
5
6
7
8
9
10
11

Number of entries
Gross weight
Net Weight
Tare
Dosed weight
Dosed tare
Average weight
A/D sample
H&B Device ID
H&B FW Version
Device Status
ADC Reference

UI8
I32
I32
I32
I32
I32
I32
I32
I32
I32
I32
I32

ro
ro
ro
ro
ro
ro
ro
ro
ro
ro
ro
ro

Number of entries in info array.
Weight and info values as 32 bit signed integer

2A00 -
2A3F

for
LDM
0..63

0
1
2
3

Number of entries.
Mass Flow Value.
Mass Flow Trend.
Total Mass.

UI8
REAL32
REAL32
REAL32

ro
ro
ro
ro

Number of entries in the mass flow data
Mass Flow Value.
Mass Flow Trend.
Total Mass.

2B00 -
2B3F

for
LDM
0..63

0
1
2
3
4
5

Number of entries.
Decimal Point.
Scale.
dTime.
dWeight.
Delay after refill

UI8
I32
I32
I32
I32
I32

ro
rw
rw
rw
rw
rw

Number of entries in the mass flow parameters.
The decimal point for the Flow value.
The scale (see below).
Delta Time measuring window.
Delta Weight measuring window.
Delay after refill.

Scale:

0,1,2 :

d/sec, d/min, d/hour,

3,4,5 :

1000 d/sec, 1000 d/min, 1000 d/hour,

6,7,8 :

1000000 d/sec, 1000000 d/min, 1000000 d/hour.

2BFF

Number of entries.
As for 2B00-2B3F

UI8
I32

ro
wo

Number of mass flow parameters.
As for 2B00 – 2B3F, except this is WRITE ONLY and the settings are
broadcasted to all LDMs.
