Manual MCS-64 Page 20
Index Sub-
index Name Type Attri-
bute Default-value Meaning
2400 -
243F
for
LDM
0..63
0
1 Number of entries
Dose Info UI8
UI16 ro
ro 1
Read the dose info:
Bit value Meaning
$0001 Coarse valve open
$0002 Fine valve open
$0004 Dose program running
$0008 Not used
$0010 Not used
$0020 Not used
$0040 Tare out of range – no filling in this cycle
$0080 Zero out of range
$FF00 The High byte has the following interpretation:
-
00= Idle
-
01= Waiting for trigger(2
nd
trigger)
-
02= Bottle on, calculating tare
-
03= Pre-fill
-
04= Main Filling
-
05= Fine Filling
-
06= In-flight delay
-
07= Post fill calculations
-
08= Post Filling
