Manual MCS-64 Page 27
3.4.2 Service data objects
SDO’s
Are only available on request
See tables 3.3 Object Directory
Can be used for complete setup of the System MCS-64 via CANbus master, e.g.:
- Filter setting channel 1: Index 2100, Subindex 4
- Filter Mode setting channel 3: Index 2102, Subindex 9
Can be used to get information regarding all the commands available, e.g.:
- Net weight channel 1: Index 2900, Subindex 2
- AD sample channel 3: Index 2902, Subindex 7
Note:
Index 2000 and 2001 refer to the CANbus standards (document DS 301, which is
available on request). Using Index 2000 and 2001 you will only get the weight information (no
channel info). Using Index 2900 – 293F you get the weight and channel information.
