Page Manual MSC-64 52
4.14 Speed Estimation Multi-Channel System MCS-64
Gateway CANopen CGM 85.1
No. of Channels Transfer Rate per Channel Remark
8 40 Measurements/sec * * new firmware in gateway required
16 20 Measurements/sec * * new firmware in gateway required
32 10 Measurements/sec
64 5 Measurements/sec
This speed estimation is for example valid for gross / net weight.
For applications like check weighers, filling, loss in weight etc. each LDM 88.1 calculates the
valid result. This means that no “data stream” will overload the CANopen traffic.
For a single channel, the data output via service port can be used for high speed
measurements, e.g. with the DOP software. The measuring rate is up to 600 meas./s.
