Manual MCS-64 Page 15

Index

Sub-
index

Name

Type

Attri-
bute

Default-value

Meaning

2000

0
1
2
3
4
5
6

Number of entries
Gross weight
Net Weight
Tare
Dosed weight
Dosed tare
Average weight

UI8
REAL32
REAL32
REAL32
REAL32
REAL32
REAL32

ro
ro
ro
ro
ro
ro
ro

Number of entries in command input array.
Weight values as 32 bit IEEE754 floating point.

2001

0
1
2
3
4
5
6
7
8
9
10
11

Number of entries
Gross weight
Net Weight
Tare
Dosed weight
Dosed tare
Average weight
A/D sample
H&B Device ID
H&B FW Version
Device Status
ADC Reference

UI8
I32
I32
I32
I32
I32
I32
I32
I32
I32
I32
I32

ro
ro
ro
ro
ro
ro
ro
ro
ro
ro
ro
ro

Number of entries in info array.
Weight and info values as 32 bit signed integer

2002

0
1
2
3

Number of entries
1

Object

UI8
UI16
UI8
UI8

ro
ro
ro
ro

Number of objects in the dosed result.
Module Status
Module ID [0...63]. The module that finished a filling cycle.
Gateway Status

2003

0
1..16

Number of entries
Hardware ID bytes

UI8
UI8

ro
ro

Number of bytes in hardware identification array.
