Index Sub-
index Name Type Attri-
bute Default-value Meaning
2600 -
263F
for
LDM
0..63
0
1
2
3
4
Number of entries.
Set-point 1
Set-point 2
Set-point 3
Set-point 4
UI8
I32
I32
I32
I32
ro
rw
rw
rw
rw
4 Number of Set-point parameters.
Set-point 1 value
Set-point 2 value
Set-point 3 value
Set-point 4 value
26FF
Number of entries.
As for 2600-263F
UI8
I32 ro
wo 4
Number of Set-point parameters
As for 2600 – 263F, except this is WRITE ONLY and the settings are
broadcasted to all LDMs
2700 -
273F
for
LDM
0..63
0
1
2
3
4
Number of entries.
Set-point 1
Set-point 2
Set-point 3
Set-point 4
UI8
I32
I32
I32
I32
ro
rw
rw
rw
rw
4 Number of Set-point parameters.
Set-point 1 hysteresis
Set-point 2 hysteresis
Set-point 3 hysteresis
Set-point 4 hysteresis
27FF
Number of entries.
As for 2700-273F
UI8
I32 ro
wo 4
Number of Set-point parameters
As for 2700 – 273F, except this is WRITE ONLY and the settings are
broadcasted to all LDMs
2800 -
283F
for
LDM
0..63
0
1
2
3
4
Number of entries.
Set-point 1
Set-point 2
Set-point 3
Set-point 4
UI8
UI8
UI8
UI8
UI8
ro
rw
rw
rw
rw
4 Number of Set-point parameters.
Set-point 1 source
Set-point 2 source
Set-point 3 source
Set-point 4 source
28FF
Number of entries.
As for 2800-283F
UI8
I32 ro
wo 4
Number of Set-point parameters
As for 2800 – 283F, except this is WRITE ONLY and the settings are
broadcasted to all LDMs
