B keyboard set up 4 – Flintec DAS 72.1 User Manual
Page 4
B
KEYBOARD SET UP
Page 4
Manual DAS 72.1
A
GENERAL
2
A.1
INTRODUCTION AND SPECIFICATION
2
A.2
KEY FUNCTIONS
3
B
KEYBOARD SET UP
4
B.1
SHORT MANUAL OF KEYBOARD SETUP
5
B.2
SETUP TABLE
6
B.3
SET UP FLOWCHARTS
7
B.3.1
Zero set up, Menu 1.1 - 1.4
7
B.3.2
Span set up, Menu 2.1 - 2.4
8
B.3.3
Display set up, Menu 3.1 - 3.4
9
B.3.4
Filter / no motion set up, Menu 4.1 - 4.4
10
B.3.5
Analogue output set up, Menu 5.1 - 5.4
11
B.3.6
Logic input set up, Menu 6.1.3 - 6.3.4
12
B.3.7
Logic output set up, Menu 7.1 - 7.3
14
B.3.8
Data communication set up, menu 8.1 - 8.4
15
B.3.9
Error codes
16
B.4
EXAMPLES
17
B.4.1
Example 1, calibration procedure using weights
17
B.4.2
Example 2, calibration procedure using load cell mV/V sensitivity and zero offset
19
B.4.3
Example 3, calibration procedure using load cell mV/V sensitivity
21
D
CE KONFORMITÄTSERKLÄRUNG
57
