EVCO S.p.A.
c-pro 3
hecto MCSA | User manual ver. 2.0 | Code 144MCSAE204
page 40 of 52
Label
Parameter description
Default
Min
Max
PM15
Manual/automatic operation of the DO6 output
0: Auto – automatic operation
1: Manu – manual operation
0 (Auto)
0 (Auto)
1 (Manu)
PM16
Forces the DO1 output in manual operating mode
0 (Off)
O (Off)
1 (On)
PM17
Forces the DO2 output in manual operating mode
0 (Off)
O (Off)
1 (On)
PM18
Forces the DO3 output in manual operating mode
0 (Off)
O (Off)
1 (On)
PM19
Forces the DO4 output in manual operating mode
0 (Off)
O (Off)
1 (On)
PM20
Forces the DO5 output in manual operating mode
0 (Off)
O (Off)
1 (On)
PM22
Manual/automatic operation of the PWM output
0: Auto – automatic operation
1: Manu – manual operation
0 (Auto)
0 (Auto)
1 (Manu)
PM23
Manual/automatic operation of the AO2 output
0: Auto – automatic operation
1: Manu – manual operation
0 (Auto)
0 (Auto)
1 (Manu)
PM25
Forces the PWM output in manual operating mode
0.0
0.0
100.0
PM26
Forces the AO2 output in manual operating mode
0.0
0.0
100.0
PM27
Forces the AO3 output in manual operating mode
0.0
0.0
100.0
MAINTENANCE TECHNICIAN PARAMETERS - CALIBRATION
PM80
Calibration of the external temperature probe
0.0
-10.0
10.0
PM81
Calibration of the supply probe
0.0
-10.0
10.0
PM82
Calibration of the zone 2 temperature probe
0.0
-10.0
10.0
PM83
Calibration of the zone 1 temperature probe
0.0
-10.0
10.0
PM84
Calibration of the zone 1 humidity probe
0.0
-10.0
10.0
INSTALLER PARAMETERS - ZONES
PZ04
Enable humidity regulation
1 (Yes)
0 (No)
1 (Yes)
PZ07
Type of zone 1 regulation (off,s,w,s/w)
0: None
1: Summer
2: Winter
3: Summer/Winter
3
0
3
PZ08
Type of zone 2 regulation (off,s,w,s/w)
0: None
1: Summer
2: Winter
3: Summer/Winter
3
0
3
PZ09
Type of zone 2 integration (off,s,w,s/w)
0: None
1: Cooling
2: Heating
3: Cooling/Heating
3
0
3
PZ10
Type of zone 1 integration (off,s,w,s/w)
0: None
1: Cooling
2: Heating
3: Cooling/Heating
3
0
3
PZ21
Zone 1 climatic curve min. ext T. (summer)
12.0
0.0
70.0
