EVCO S.p.A. c-pro 3 hecto MCSA | User manual ver. 2.0 | Code 144MCSAE204
page 24 of 52
0 Disabled
1 Zone 1 collector
2 Zone 2 collector
3 Dehumidifier collector
4 Chiller/heat pump/boiler activation remote
control
5 Chiller remote control
6 Boiler remote control
7 Summer/Winter control
8 General alarm
9 Pump
10 Auxiliary dehumidifier control
11 Hot/Cold booster
For all I/O's it is necessary to define the desired use by setting the relative parameters appropriately. Moreover, the
polarity must be defined for every digital input and output and for the analogue outputs used as digital in this
application, via dedicated parameters.
The MCSA I/O's can therefore be modified according to requirements. It is also possible to give the same meaning to
several outputs; this is not allowed for the inputs (a configuration error is signalled).
The page used to change all four level passwords can also be accessed from the manufacturer menu.
3.12 Password
A level is associated to every menu (except clock and log), which conditions its accessibility. Every level has a
password associated that allows access to the various functions present in that determined menu. The protected
functionalities can be accessed once the correct password has been introduced. By entering a password correctly,
there are two effects:
release of the correlated level
release of the sub-levels
Every password level can be modified from the same or higher level. For example, from the manufacturer level it is
possible to modify all passwords of the lower levels.
Here is an example of the password page from manufacturer menu.
The accepted range of values for the password is: -999 / 9999.
If no action is performed on this page, after 4 minutes, the password entered expires and it must be entered again.
