EVCO S.p.A. EVFTFT618 | Installer manual ver. 2.2 | Code 144FTFT618E224
Page 6 of 62
1.2 Summary table of the main features and the models
available
The following table illustrates the main features of the device.
“ / “ indicates the feature can be set via a configuration parameter.
User interface (without cover)
200.0 x 135.0 mm (7.874 x 13.498 cm; L x H) •
320 x 240 pixel
(3.5 inch) colour TFT graphics display
•
number of keys (capacitive touch-key type) 11
Control module (without cover)
166.0 x 116.0 mm (6.535 x 11.598 cm; L x H) •
Connections
removable screw terminal board •
Power supply
115-230 VAC •
Analogue inputs
cabinet probe PTC/NTC
evaporator probe PTC/NTC
condenser probe PTC/NTC
humidity transducer 4-20mA
Digital inputs (for NO/NC contact)
door micro switch •
high pressure •
low pressure •
compressor circuit breaker protection •
Analogue outputs (PWM)
evaporator fan (1)
