40 - Feature Overview RocketLinx ES7510-XT User Guide: 2000571 Rev. D
Configuration Using the Web User Interface
DHCP Server
Configuration
DHCP Server
Configuration
on
Page 55
DHCP Leased
Entries
on Page 57
DHCP Relay Agent
on Page 58
• DHCP Server Configuration
- Excluded Addresses and Manual Binding
- Port and IP Address
- Option 82
• DHCP Leased Entries
• DHCP Relay Agent
- Helper Address 1-4
- DHCP Option82 Relay Agent (Circuit ID/Remote ID)
DSCP-Queuing
Mapping
DSCP-Queue
Mapping
on Page
103
• DSCP 0 through 7
• Queue 0 through 3
• Queue 3 highest priority
Event Selection
Event Selection on
Page 119
• Device Cold Start
• Device Warm Start
• Authentication Failure
• Time Synchronization Failure
• Power 1 Failure
• Power 2 Failure
• Fault Relay
• Ring Topology Change
• SFP
• Port by Port Event Selection
• Port by Port PoE Event Selection
Fault Relay
Warning on Page
117
Relay 1- Multi-event
• Power - DC1, DC2, or All
• Port Link (Port or Ports)
• Ring Failure
• Ping Failure - IP Address
• Ping Reset, IP Address, Reset Time (Sec), and Hold Time
(Sec)
• Dry Output - On Period (Sec) and Off Period (Sec)
• DI - State (High or Low)
GMRP
Configuration Multicast Filtering
on Page 104
• Enable/Disable
• Port by Port Basis
GVRP Configuration
GVRP
Configuration
on
Page 96
• 2K Entries
• Enable/Disable GVRP Protocol
• State - Enable/Disable
• Join Timer
• Leave Timer
• Leave All Timer
Type Category Details
