KEYENCE BL-N70 Series User Manual
Page 69
A-5 Replacing the Communication Cable
-15
Ap
pend
ices
z Connecting the communication cable
1
Insert the modular jack for the replacement communication cable into the connector for the
BL-N70 cable.
Grasp the cord protector for the communication cable and insert it forcefully into the connector
until you hear a clicking sound.
Gently pull on the cord protector for the connection cable to verify that it is locked into place.
Connection is complete.
Communication
cable connecto
Modular jack
Modular jack tab
