A-4 Settings and the Factory Default Values
-8
Ap
pend
ices
z Detailed symbology settings
Setting item Setting content
UPC/EAN EAN13 ON (Enabled)
OFF (Disabled)
EAN8 ON (Enabled)
OFF (Disabled)
UPC-A ON (Enabled)
OFF (Disabled)
UPC-E ON (Enabled)
OFF (Disabled)
Extended UPC-A Send 12 digits
Send 13 digits
UPC-E settings System code 0 omitted
System code 0 added
Handling
Supplementals 2 digit add-on enabled
2 digit add-on disabled
5 digit add-on enabled
5 digit add-on disabled
Reading the
Supplemental
codes only ON (Enabled)
OFF (Disabled)
Check digit Send the UPC-A check digit
Do not send the UPC-A check digit
Send the UPC-E check digit
Do not send the UPC-E check digit
Send the EAN 8 digit check digit
Do not send the EAN 8 digit check digit
Send the EAN 13 digit check digit
Do not send the EAN 13 digit check digit
CODE128
(EAN128) EAN128 ON (Enabled)
OFF (Disabled)
Sending ]c1 Send
Do not send
Group separator [GS]
[SPC]
Highlighted items indicate factory defaults.
