Table of Indicated States
This appendix describes the various indicated states of the SJ-F100W/100/010.
„ Indicated states when the power is turned ON
Lit State Description
The state (charged level indication or ion
level indication) that was active before
the power was turned OFF is displayed.
At the same time, the alarm indicator, ion
level alarm indicator, and condition alarm
indicator light (red).
When the power is turned ON, the indicated state (charged level
indication or ion level indication) that was active before the power
was turned OFF is displayed. Also, the alarm indicator, ion level
alarm indicator and condition alarm indicator light (red) at the
same time. After this indication state continues for about two
seconds, the ion monitor LEDs fluctuate upward and downward,
and static elimination is then started. After static elimination starts,
the charged level or ion level is indicated.
+
–
0
BALANCE ION
ION
LEVEL
COND
DISP
ALARM
+
–
0
BALANCE ION
ION
LEVEL
COND
DISP
ALARM
H
M
L
H
M
L
H
M
L
H
M
L
The ion monitor LEDs fluctuate
upward and downward.
