2-10
2
2 Screen Functions and Operation
Add bet. OUT/Sub bet. OUT/AVE bet. OUT/P-P bet. OUT/MAX bet. OUT/MIN bet. OUT
Sets the type of output value to associate with the OUT.
The operation specified from the "Type" options is applied to the checked OUTs.
• Add bet. OUT: Sum of the checked OUTs
• Sub bet. OUT: Difference of the checked OUTs
• AVE bet. OUT: Average of the checked OUTs
• P-P bet. OUT: Maximum to minimum value of the checked OUTs
• MIN bet. OUT: Minimum of the checked OUTs
• MAX bet. OUT: Maximum of the checked OUTs
(3) Copy/Paste
Use this button to copy the OUT settings to another OUT (or an OUT in a different program
number).
 Copying the OUT settings to another OUT
This example explains how to copy the settings for OUT01 to OUT02
1
Complete all settings for "OUT01".
2
Touch "Copy".
3
Touch "OUT".
The "Out Settings" dialog box appears.
4
Touch "OUT02".
5
Touch "Paste".
The settings for OUT01 are copied to OUT02.
