5 Putting into operation
54 K-375/376/377 Operation Manual, Version B
Front view:
Rear view: The crosshair marks the sensitive area
Status LED
Adjustment screw
b
Fig. 5.9: Fixing the level sensors
NOTE
The sensor detects a liquid when the red LED is
off.
The level sensor for the waste tank must be set active within the Settings  Peripherals screen (See
chapter “6.9.1 Settings“). This is not necessary for the other sensors.
