7 Maintenance
138 K-375/376/377 Operation Manual, Version B
7 .7 Maintenance work if required
7 .7 .1 Changing the buret tip
The buret tip consists of the shaft d with threaded clamping b and slip-on tip e. The buret tip is
inserted into the receiver vessel using the distance holder c.
a
b
c
d
e
a Hose
b Threaded clamping
c Distance holder
d Shaft
e Slip-on tip
Fig. 7.2: Disassembling and assembling a buret tip
To assemble the buret tip, proceed as follows:
1. Screw the shaft d to the hose a.
2. Slip the distance holder c onto the shaft.
3. Push the slip-on tip e onto the end of the shaft.
