Chapter 5 - MODBUS-RTU Communication
84
< FU2 Group >
Parameter
address
Parameter
Code
Description
Default
value
Max. value
Min value
Unit
Note
630A
FU2 #10
Jump freq
0
1
0
630B
FU2 #11
Jump lo 1
0
FU2-12
0
0.01Hz
630C
FU2#12 Jump
Hi
1 0 FU1-20 FU2-11 0.01Hz
630D
FU2 #13
Jump lo 2
0
FU2-14
0
0.01Hz
630E
FU2 #14
jump Hi 2
0
FU1-20
FU2-13
0.01Hz
630F
FU2 #15
jump lo 3
0
FU2-16
0
0.01Hz
6310
FU2 #16
jump Hi 3
0
FU1-20
FU2-15
0.01Hz
6314
FU2 #20
Power-on run
0
1
0
6315
FU2 #21
RST restart
0
1
0
6316 FU2
#22 ssMode 0000 1111
0000
6317 FU2
#23 ssStallPerc 180 200
80
%
6318
FU2 #24
SS P-Gain
100
9999
0
6319
FU2 #25
SS I-Gain
1000
9999
0
631A
FU2 #26
Retry number
0
10
0
631B
FU2 #27
Retry delay
10
600
0
0.1sec
631E
FU2 #30
Motor select
*
5
0
631F
FU2 #31
Pole number
4
12
2
6320 FU2
#32 Rated-Slip * 1000
0 0.01Hz
6321
FU2
#33
Rated-Curr * 999 1 0.1A
6322
FU2
#34
Noload-Curr
* 999 1 0.1A
6324 FU2
#36 Efficiency *
100
50
%
6325 FU2
#37 Inertiarate 0
2
0
6327
FU2 #39
Carrier freq
30
100
10
0.1kHZ
6328
FU2 #40
Control mode
0
2
0
6332
FU2 #50
PID F/B
0
1
0
6333
FU2 #51
PID P-gain
3000
9999
0
6334
FU2 #52
PID I-time
300
9999
0
6335
FU2 #53
PID D-time
0
9999
0
6336
FU2 #54
PID limit
5000
FU1-20
0
0.01Hz
6346
FU2 #70
Acc/Dec freq
0
1
0
6347
FU2 #71
Time scale
1
2
0
6348
FU2 #72
PowerOn disp
0
13
0
6349
FU2 #73
User disp
0
2
0
634A
FU2 #74
RPM factor
100
1000
1
%
634B
FU2#75
DB
Mode
2 2 0
634C
FU2#76
DB % ED
10
30
0
%
634F
FU2 #79
S/W version
6351
FU2 #81
2nd Acc time
50
9999
0
0.1sec
6352
FU2 #82
2nd Dec time
100
9999
0
0.1sec
6353
FU2 #83
2nd BaseFreq
5000
FU1-20
3000
0.01Hz
