Cleveland Range inverter User Manual
Page 88
Chapter 5 - MODBUS-RTU Communication
82
Parameter
address
Description
Unit
Read/Write
Data value (HEX)
Note
Bit 2: BX
Bit 3: RST-
Bit 8: P1
Bit 9: P2
Bit 10: P3
0011
Output terminal info
-
R
Bit 0: Q1 (OC)
0012
V1
-
R
0 – FFFF
0013 V2
-
-
Not
used
0014
I
-
R
0 – FFFF
0015 RPM
-
R
< DRV Group >
Parameter
address(*3)
Parameter
Code
Description
Default
value
Max. value
Min. value
Unit
Note
6100
DRV #00
Cmd. Freq.
5000
FU1-20 (*1)
FU1-22 (*2)
0.01Hz
6101
DRV #01
Acc. Time
100
9999
0
0.1 sec
6102
DRV #02
Dec. Time
200
9999
0
0.1 sec
6103
DRV #03
Drive mode
1
2
0
6104
DRV #04
Freq. mode
2
4
0
6105
DRV #05
Speed - 1
1000
FU1-20
0
0.01Hz
6106
DRV #06
Speed - 2
2000
FU1-20
0
0.01Hz
6107
DRV #07
Speed - 3
3000
FU1-20
0
0.01Hz
6108
DRV #08
Output Current
0
-
-
0.1A
Read Only
6109
DRV #09
Output speed
0
-
-
RPM
Read Only
610A
DRV #10
DC Link Voltage
0
-
-
0.1V
Read Only
(*1) Refer to FU1 #20 for Max Freq.
(*2) Refer to FU1 #22 for Start Freq.
(*3) Parameter address is HEX data
< FU1 Group >
Parameter
address
Parameter
Code
Description
Default
value
Max. value
Min. value
Unit
Note
6203
FU1 #03
Run prohibit
0
2
0
6205
FU1 #05
Acc. pattern
0
4
0
6206
FU1 #06
Dec. pattern
0
4
0
6207
FU1 #07
Stop mode
0
2
0
6208
FU1 #08
DcBr freq.
500
5000
FU1-22
0.01 Hz
6209
FU1 #09
DcBlk time
10
6000
0
0.01 sec
620A
FU1 #10
DcBr value
50
200
0
1%
620B
FU1 #11
DcBr time
10
600
0
0.1sec
