Chapter 3 - Parameter List
30
Code Description
Keypad
Display
Setting Range Units
Factory
Default
Adj.
During
Run
Page
0 (No)
1 (All Groups)
2 (DRV)
3 (FU1)
4 (FU2)
FU2-93 Initialize Parameters H 93
5 (I/O)
- 0 (No) No 60
FU2-94 Parameter Write Protection H 94 0 to 255 18 1 0 Yes 60
FU2-99 Return Code rt - - Yes 60
3.4 Input/Output Group [I/O]
Code Description
Keypad
Display
Setting Range Units
Factory
Default
Adj.
During
Run
Page
I/O-00 Jump to Desired Code # I 0 1 to 99 1 1 Yes 62
I/O-01
Filtering Time Constant for V1
Signal Input
I 1 0 to 9999 [ms] 1 100 [ms] Yes
I/O-02 V1 Input Minimum Voltage I 2 0 to I/O-04 0.01 0.00 [V] Yes
I/O-03
Frequency corresponding to V1
Input Minimum Voltage
I 3 0 to FU1-20 0.01 0.00 [Hz] Yes
I/O-04 V1 Input Maximum Voltage I 4 (I/O-02) to 12.00 [V] 0.01 10.00 [V] Yes
I/O-05
Frequency corresponding to V1
Input Maximum Voltage
I 5 0.00 to (FU1-20) 0.01 50 / 60 [Hz] Yes
62
I/O-06
Filtering Time Constant for I Signal
Input
I 6 0 to 9,999 [ms] 1 100 [ms] Yes
I/O-07 I Input Minimum Current I 7 0.00 to (I/O-09) 0.01 4.00 [mA] Yes
I/O-08
Frequency corresponding to I Input
Minimum Current
I 8 0.00 to (FU1-20) 0.01 0.00 [Hz] Yes
I/O-09 I Input Maximum Current I 9 (I/O-07) to 24.00[mA] 0.01 20.00 [mA] Yes
I/O-10
Frequency corresponding to I Input
Maximum Current
I 10 0.00 to (FU1-20) 0.01 50 /60 [Hz] Yes
62
0 (None)
1 (Half of x1)
I/O-11 Criteria for Analog Input Signal Loss I 11
2 (Below x1)
- 0 (No) Yes 63
0 (Speed-L)
1 (Speed-M) I/O-12 Multi-function Input Terminal ‘P1’
Define
I 12
2 (Speed-H)
- 0 (Speed-L) No 64
18 This function is used to lock the parameters from being changed. Keypad displays “U 0” when the parameters are unlocked and “L 0” when
locked. The lock and unlock code is ‘12’.
