RFI Filters (Footprint - Standard) for ACtionMaster SERIES
(x) (1) Industrial environment EN 50081-0 (A class)
(2) Domestic and industrial environment EN 50081-1 (B class)
iG5
series / Filtros Footprint / Footprint Filters
VARIADOR
INVERTER
POT.
POWER
CODIGO
CODE
INTENS.
CURRENT
TENSION
VOLTAGE
CORRIENTE
DE FUGAS
LEAKAGE
CURRENT
DIMENSIONES
DIMENSIONS
L W H
MONTAJE
MOUNTING
Y X
PESO
WEIGHT
TORNILLOS
DE FIJACION
MOUNT
CHOQUES
DE SALIDA
OUTPUT
CHOKES
MONOFASICOS SINGLE PHASE ( max. )
SV004iG5-1
0.4kW
FFG5-M010-1
10A
250VAC
3.5mA
173.5 x 103.5 x 40
159.5 x 80
M4
FS – 1
SV008iG5-1
0.8kW
FFG5-M011-1
11A 250VAC
3.5mA
173.5 x 133.5 x 40
159.5 x 110
M4
FS – 1
SV015iG5-1
1.5kW
FFG5-M020-1
20A
250VAC
3.5mA
173.5 x 153.5 x 45
159.5 x 130
M4
FS – 2
TRIFASICOS THREE PHASE NOM. MAX.
SV004iG5-2
0.4kW
SV008iG5-2
0.8kW
FFG5-T005-1
5A
250VAC
0.3mA 18mA
173.5 x 103.5 x 40
159.5 x 80
M4
FS – 1
SV015iG5-2
1.5kW
FFG5-T012-1
12A
250VAC
0.3mA 18mA
173.5 x 133.5 x 40
159.5 x 110
M4
FS – 2
SV022iG5-2
2.2kW
SV040iG5-2
4.0kW
FFG5-T020-1
20A
250VAC
0.3mA 18mA
173.5 x 153.5 x 45
159.5 x 130
M4
FS – 2
SV004iG5-4
0.4kW
SV008iG5-4
0.8kW
SV015iG5-4
1.5kW
FFG5-T006-1
6A
380 VAC
0.5mA 27mA
173.5 x 133.5 x 40
159.5 x 110
M4
FS – 1
SV022iG5-4
2.2kW
SV040iG5-4
4.0kW
FFG5-T011-1
11A
380 VAC
0.5mA 27mA
173.5 x 153.5 x 45
159.5 x 130
M4
FS – 2
iG5
series / Filtros Estándar / Standard Filters
VARIADOR
INVERTER
POT.
POWER
CODIGO
CODE
INTENS.
CURRENT
TENSION
VOLTAGE
CORRIENTE
DE FUGAS
LEAKAGE
CURRENT
DIMENSIONES
DIMENSIONS
L W H
MONTAJE
MOUNTING
Y X
PESO
WEIGHT
TORNILLOS
DE FIJACION
MOUNT
CHOQUES
DE SALIDA
OUTPUT
CHOKES
MONOFASICOS SINGLE PHASE ( max. )
SV004iG5-1
0.4kW
SV008iG5-1
0.8kW
FE-M010-( x )
10A
250VAC
3.5mA
150 x 55 x 45
140 x 36
---
FS – 1
SV015iG5-1
1.5kW
FE-M015-( x )
15A 250VAC
3.5mA
150 x 55 x 45
140 x 36
---
FS – 2
TRIFASICOS THREE PHASE NOM. MAX.
SV004iG5-2
0.4kW
SV008iG5-2
0.8kW
FE-T006-( x )
6A
250VAC
0.3mA 18mA
250 x 110 x 60
238 x 76
---
FS – 2
SV015iG5-2
1.5kW
FE-T012-( x )
12A
250VAC
0.3mA 18mA
250 x 110 x 60
238 x 76
---
FS – 2
SV022iG5-2
2.2kW
SV040iG5-2
4.0kW
FE-T020-( x )
20A
250VAC
0.3mA 18mA
270 x 140 x 60
258 x 106
---
FS – 2
SV004iG5-4
0.4kW
SV008iG5-4
0.8kW
SV015iG5-4
1.5kW
FE-T006-( x )
6A
380VAC
0.5mA 27mA
250 x 110 x 60
238 x 76
---
FS – 2
SV022iG5-4
2.2kW
SV040iG5-4
4.0kW
FE-T012-( x )
12A
380VAC
0.5mA 27mA
250 x 110 x 60
238 x 76
---
FS – 2
