Page 28

9145 NID Software User’s Manual
18
The World Leader in Fiber Optic Communications Systems
Figure 3-5. Host Table Menu
3.1.5 Trap/Notification Destination Table
The Trap Table menu (see Figure 3-6), allows the customer to determine where the trap will be
set by specifying Host Management IP Address, the port, trap type, and security level.
Figure 3-6. Trap Table Menu
3.2 Trap Configuration
Trap configuration defines the handling of various alarm events. You can log and/or send each
event, as well as disable the traps. From the System Configuration menu, type 2 and press
configurable states. The traps can be set to Log Only, Send Only, Both Log and Send, or Dis-
abled.
Canoga Perkins Corp. Ethernet Network Interface Device 04-Jan-2008
Model 9145-4 V06.0 F121 02:59:35
--------------------------------HOST ACCESS TABLE-------------------------------
Managing Host
Telnet FTP
SNMP SNMP V1/V2c Rd V1/V2c Wr
IP/Mask
Bits
Access Access
Access Protocol Community Community
172.016.002.034/32 All All Write V1/V2c/V3 public
private
172.016.015.072/32 All All Write V1/V2c/V3 public
private
Select [(A)dd, (D)elete, (E)dit, (M)ore]:
------------------------------------Messages------------------------------------
Canoga Perkins Corp. Ethernet Network Interface Device 04-Jan-2008
Model 9145-4 V06.0 F121 02:59:35
---------------------TRAP/NOTIFICATION DESTINATION TABLE---------------------
---
Managing
Trap
Username/ Security
Host
Port
Type
Community Level
172.016.002.040 162
V1-Trap
public
N/A
Select [(A)dd, (D)elete, (E)dit, (M)ore]:
------------------------------------Messages------------------------------------
