128
Rev 3 Aug/2004 KMD 150 Pilot's Guide
Developing Cluster Within the 25 nm Range Ring
Figure 13-16 shows a developing thunderstorm 12 nm from the aircraft.
If you see a screen such as this with a developing cluster within the 25
nm range ring, you should change course to avoid the storm and con-
tinue to monitor the Stormscope
® screen.
Figure 13-16 - Developing Cluster Within 25 nm Range Ring
Stormscope ® Operation
