9. Technical Data Medi Client IIA - Instructions for use (Version 1.03)
9.
Technical Data
Medi Client IIA (Class II Equipment) Medi Client IIA 104 Medi Client IIA 150
Screen size & Active area (H x V) [mm] 10.4"; 211.2 x 158.4mm 15” 304.1 x 228.1
Resolution (H x V) [pixel] 800 x 600 (SVGA) 1024 x 768 (XGA)
Pixel Pitch (H x V) [mm] 0.264 x 0.264 0.297 x 0.297
Colour depth 262k 16.2 M
Backlight 1x CCFL 2x CCFL
Brightness cd/m 2 230 350
Control signal 1x 6bit LVDS 1x 6bit LVDS
Viewing angle (r / l / u / d) 70 / 70 / 55 / 65 70/70/65/60
TFT LCD
Display
Contrast ratio 500:1 700: 1
Touch Screen 4 wire resistive analog 4 wire resistive analog
VESA ® 75/100 compliant VESA ® 75 VESA ® 75/100
Single Board Computer with Intel® Atom™ CPU 5
Lithium Battery
3.0 V for RTC, Type: CR2032, UL recognized
5
Controls and Indicators
Power Button [on the front and bottom (rear) side] 5
Power LED [on the front and bottom (rear) side] 5
HDD LED on the bottom (rear) side 5
Reset Button [on the bottom (rear) side] 5
Interfaces [on the bottom (rear) side]
USB 2.0 2x
LAN1, LAN2 Ethernet (10/100/1000 Mbps) 2x
VGA 1x
Serial Port RS232 (with mounted ESD protection cover) 1x
Interfaces (on the left side)
USB 2.0 1x
DC IN Power Connector [
3-Pin Connector
on the bottom (rear) side]
5
BIOS AMI
Operating System Refer to the Datasheet for Medi Client IIA on our Website
www.kontron.com
Protection Class
(system)
IP 21 according IEC 60529
5
Optional Parts
Storage Media CF Card and/or 2.5" SATA HDD (not included)
DC Power Terminal (3-Pin Phoenix Conn.)
External AC/DC Adapter (Class II equipment) with
corresponding power cable for EU or for UK or for US
Screws for VESA ® 75/100 mounting M4x8 zinc-coated Phillips screws (PN: 0-0068-1058)
or
M4x8 V2A stainless steel Allen screws flat-head (PN: 0-0068-2575)
38 www.kontron.com
