7.2.5.7.
Extension as CAN BUS Interface
The factory settings for SJA1000-base address, the SJA-interrupt, and the NVRAM operation mode.
Factory settings for the CAN BUS interface
Fig. 20: Color used in the Table 9, Table 10 and Table 11:
SJA Base Address
Address Range
0x340 to 0x35F
0x320 to 0x33F
0x300 to 0x31F
0x220 to 0x23F
0x200 to 0x21F
1
0x140 to 0x15F
0x120 to 0x13F
0x100 to 0x11F
Table 9: SJA-Base Address Settings
SJA-Interrupt
IRQ
disabled
15
11
10
7
5
4
3
Table 10: SJA-Interrupt Settings
NVRAM-Operation Mode
Mode
disabled
IO-mode
Memory at C0000
Memory at D0000
Table 11: NVRAM-Operation Mode Settings
