7. Product Description Medi Client IIA - Instructions for use (Version 1.03)
7.1. Front Side View
Fig. 7: Front view of the Medi Client IIA (shown as Medi Client IIA 104)
1
3 4
2
1 Front plate
2 10.4 "TFT display with touch screen 3 Power button
4 Power LED
At the front side are located:
‰ Power button and power LED
‰ Front plate for the 10.4"/15" display
‰ 10.4"/15" display with corresponding resistive touch screen
For the outline dimensions of unit are refer to the chapter 9.3 “Mechanical Specifications”.
7.1.1. Power Button on the Front Side
The power button (Fig. 7, pos. 3) allows to power ON or OFF the Medi Client IIA system. This power button works in an
“OR” function together with the power button located on the interface side. Refer to the section 7.2.2 “Power Button on
the Interface Side).
