7. Product Description Medi Client IIA - Instructions for use (Version 1.03)
7.1.2. Power LED on the Front Side
The power LED (Fig. 7, pos. 4) indicates the power states of the system.
The system is connected to the
power source Power Button (front/rear) Power LED (front) Medi Client IIA System Status
Off orange The system is in “standby”
Medi Client IIA
On green The system is running.
Table 5: System Power states
Please observe that this power LED does not indicate error codes if malfunction conditions of the system
occur. Only the power LED (Fig. 13, Pos. 10) on the interface side signals a malfunction condition via
error codes (Refer to the section 8.2).
Even when the system is turned off via power button (front or rear) there is still a standby-voltage of
5 V on the SBC board. The system is not completely disconnected from the main power source by turning
off via the power button.
Hints for DC power connection:
The DC main power supply should be able to be switched off and on via a 2-pole isolating switch.
The unit is only completely disconnected from the DC main power supply, when the DC power cord is
disconnected either from the DC main or the unit. Therefore, the DC power cord and its connectors must
always remain easily accessible.
Hints for AC power connection via the optional external AC/DC adapter:
The main power cable of the external AC/DC adapter serves as disconnecting device. For this reason the
outlet of the AC power source must be located close to the device and be easily accessible.
7.1.3. Display (10.4"/15") with Touch Screen
The built-in display is a 10.4"or a 15" size TFT display with corresponding resistive touch screen. The touch screen is
USB connected. For technical specification of the built-in display refer to the chapter 9 “Technical Data”.
The display is equipped with a resistive touch screen. The touch screen offers the same degree of user comfort as the
mouse buttons. A stylus is supplied for touch screen operation. The surface of the display is also mechanically protected
through the touch screen. The touch screen registers contacts of a finger or a pen and allows moving the mouse pointer.
Use a stylus (included) for best results.
You get the corresponding touch screen driver for your operating system, installed on your Medi Client IIA system.
Do not use a hard or a pointed object (like screw drivers) to operate the touch screen, since it can
damage the touch screen surface.
For cleaning and disinfection of the Medi Client IIA please refer to chapter 8.3 and 8.4.
