COMe-P2020 User Guide
86
USAGE: 1. Display available configurations:
=> sconf info
Default configuration active
Listing available base configurations
=========+-===============+-===============+-===============+-
===============
Base | Serdes #0 | Serdes #1 | Serdes #2 | Serdes #3
Config | | | |
=========+-===============+-===============+-===============+-
===============
|
< 0> | OFF OFF OFF OFF
|
**< 1>**| PCIEx4 @2.5 RC
|
< 2> | PCIEx1 @2.5 RC PCIEx1 @2.5 RC PCIEx2 @2.5 RC
|
< 3> | PCIEx2 @2.5 RC PCIEx2 @2.5 RC
|
< 4> | PCIEx1 @2.5 RC PCIEx1 @2.5 RC SGMII SGMII
|
< 5> | PCIEx2 @2.5 RC SGMII SGMII
|
< 6> | PCIEx1 @2.5 RC SRIOx1 @2.5 H SGMII SGMII
|
[ 7] | SRIOx1 @2.5 H SRIOx1 @2.5 H SGMII SGMII
|
< 8> | SRIOx4 @3.125H
eTSEC2 configured in SGMII mode
eTSEC3 configured in SGMII mode
SRIO host mode, device ID is 0
Boot ROM location is spi
=>
Table 6-6: sconf Command (Continued)
