Table 3-71: 0x37B: Board Interrupt Enable Register 2
ACTION D7 D6 D5 D4 D3 D2 D1 D0
READ En7 En6 En5 En4 En3 En2 En1 En0
WRITE En7 En6 En5 En4 En3 En2 En1 En0
POWER UP 0 0 0 0 0 0 0 0
BITFIELD DESCRIPTION
[D0] En0 Enable bit for CON_SMB_ALERT# Interrupt Request Register:
'0' = no Interrupt
'1' = Interrupt is active
[D1] En1 Enable bit for LM73_TEMP_ALERT# Interrupt Request Register:
'0' = no Interrupt
'1' = Interrupt is active
[D2] En2 Enable bit for CON_THERM# Interrupt Request Register:
'0' = no Interrupt
'1' = Interrupt is active
[D3] En3 Enable bit for CON_PWR_OK# Interrupt Request Register:
'0' = no Interrupt
'1' = Interrupt is active
[D4] En4 Enable bit for CON_BATLOW# Interrupt Request Register:
'0' = no Interrupt
'1' = Interrupt is active
[D5] En5 Enable bit for RTC_INT# Interrupt Request Register:
'0' = no Interrupt
'1' = Interrupt is active
[D6] En6 Enable bit for CON_WAKE0# Interrupt Request Register:
'0' = no Interrupt
'1' = Interrupt is active
[D7] En7 Enable bit for CON_WAKE1# Interrupt Request Register:
'0' = no Interrupt
'1' = Interrupt is active
Table 3-72: 0x37C: Board Interrupt Enable Register 3
ACTION D7 D6 D5 D4 D3 D2 D1 D0
READ 0 0 0 0 0 0 0 En0
WRITE NU NU NU NU NU NU NU En0
POWER UP 0 0 0 0 0 0 0 0
BITFIELD DESCRIPTION
[D0] En0 Enable bit for WATCHDOG Interrupt Request Register:
'0' = no Interrupt
'1' = Interrupt is active
