COMe-P2020 User Guide
32
D97 RSVD19 Local Bus O-3.3 LA19
D98 SERDES_TX22+ SERDES N/C
D99 SERDES_TX22- SERDES N/C
D100 GND PWR GND
D101 SERDES_TX23+ SERDES N/C
D102 SERDES_TX23- SERDES N/C
D103 GND PWR GND
D104 VCC_12V PWR VCC_12V
D105 VCC_12V PWR VCC_12V
D106 VCC_12V PWR VCC_12V
D107 VCC_12V PWR VCC_12V
D108 VCC_12V PWR VCC_12V
D109 VCC_12V PWR VCC_12V
D110 GND PWR GND
Table 2-5: General Signal Description
TYPE DESCRIPTION
I/O-3.3 Bi-directional 3.3V IO-Signal
I-3.3 3.3V Input
O-3.3 3.3V Output
OD-3.3 Open-Drain Output
DP-I/O Differential Pair Input/Output
DP-I Differential Pair Input
DP-O Differential Pair Output
PDS Pulldown Strap
STRAP
Straping Input during Power-Up (do
not connect any external Pullup or
Pulldown resistor)
PWR Power Connection
Table 2-4: Connector J2 Row D Pinout (Continued)
PIN SIGNAL
SIGNAL
GROUP
TYPE TERMINATION COMMENT
