Table 3-33: 0x288: Board ID High Byte Register
ACTION D7 D6 D5 D4 D3 D2 D1 D0
READ Board-Register-High-Byte[7:0]
WRITE Board-Register-High-Byte[7:0]
POWER UP 1 1 0 1 0 0 0 0
BITFIELD DESCRIPTION
[D0-D7] Board-Register-High-Byte[7:0] Board Identif ication High Byte:
COMe_P2020: 0xD048
Table 3-34: 0x289: Board and PLD Revision Register
ACTION D7 D6 D5 D4 D3 D2 D1 D0
READ Revision-Byte[7:0]
WRITE Revision-Byte[7:0]
POWER UP 0 0 0 0 0 0 0 0
BITFIELD DESCRIPTION
[D0-D7] Revision-Byte[7:0] Board Revision identif ication
Revision-Byte[7:0] PLD Revision identif ication
