1.4 Standards
The COMe-cP2020 complies with the requirements of the following standards.
Table 1-2: Standards
COMPLIANCE TYPE STANDARD TEST LEVEL
CE Emission EN55022
EN61000-6-3 --
Immission EN55024
EN61000-6-2 --
Electrical Safety EN60950-1 --
Railway Safety Electrical Safety EN50155 --
Mechanical Mechanical Dimensions COM Express® com-
pact --
Environmental
and Health
Aspects Vibration
(sinusoidal, operating) EN 50155
IEC 60068-2-6
VITA 47
Class 1B
Frequency:10 - 300 Hz
Acceleration: 5 g
Class V1
5 to 100Hz
~2g RMS
Shock (operating) EN 50155 Class 1B
Bump
Operating IEC
60068-2-29 Peak Accel.: 15 g
Shock Dur.: 11 ms half sine
Shock Count: 500
Climatic Humidity IEC60068-2-78 93% RH at 40°C, non-condensing
(see notice below)
WEEE Directive 2002/96/EC Waste electrical and electronic
equipment
RoHS-II Directive 2011/65/EC Restriction of the use of certain
hazardous substances in electri-
cal and electronic equipment
