COMe-P2020 User Guide
31
D49 LA14 Local Bus O-3.3 LA28
D50 IRQ_OUT# IRQ O-3.3 Undefined
D51 GND PWR GND
D52 SERDES_TX8+ SERDES N/C
D53 SERDES_TX8- SERDES N/C
D54 PEG_LANE_RV# PCIE/SERDES I-3.3 Undefined
D55 SERDES_TX9+ SERDES N/C
D56 SERDES_TX9- SERDES N/C
D57 T YPE2# T YPE 0 Single 4K7 pull down, DNI
D58 SERDES_TX10+ SERDES DP-O MUX_PCIE_TX2_P
D59 SERDES_TX10- SERDES DP-O MUX_PCIE_TX2_N
D60 GND PWR GND
D61 SERDES_TX11+ SERDES DP-O MUX_PCIE_TX3_P
D62 SERDES_TX11- SERDES DP-O MUX_PCIE_TX3_N
D63 RSVD19 Local Bus O-3.3 LA27
D64 RSVD19 Local Bus O-3.3 LA26
D65 SERDES_TX12+ SERDES N/C
D66 SERDES_TX12- SERDES N/C
D67 GND PWR GND
D68 SERDES_TX13+ SERDES N/C
D69 SERDES_TX13- SERDES N/C
D70 GND PWR GND
D71 SERDES_TX14+ SERDES N/C
D72 SERDES_TX14- SERDES N/C
D73 GND PWR GND
D74 SERDES_TX15+ SERDES N/C
D75 SERDES_TX15- SERDES N/C
D76 GND PWR GND
D77 IRQ5# IRQ I-3.3 Undefined
D78 SERDES_TX16+ SERDES N/C
D79 SERDES_TX16- SERDES N/C
D80 GND PWR GND
D81 SERDES_TX17+ SERDES N/C
D82 SERDES_TX17- SERDES N/C
D83 T YPE3# T YPE 0 Single 4K7 pull down, DNI
D84 GND PWR GND
D85 SERDES_TX18+ SERDES N/C
D86 SERDES_TX18- SERDES N/C
D87 GND PWR GND
D88 SERDES_TX19+ SERDES N/C
D89 SERDES_TX19- SERDES N/C
D90 GND PWR GND
D91 SERDES_TX20+ SERDES N/C
D92 SERDES_TX20- SERDES N/C
D93 GND PWR GND
D94 SERDES_TX21+ SERDES N/C
D95 SERDES_TX21- SERDES N/C
D96 GND PWR GND
Table 2-4: Connector J2 Row D Pinout (Continued)
PIN SIGNAL
SIGNAL
GROUP
TYPE TERMINATION COMMENT
