COMe-P2020 User Guide
23
A71 LVDS_A0+ LVDS RSVD
A72 LVDS_A0- LVDS RSVD
A73 LVDS_A1+ LVDS RSVD
A74 LVDS_A1- LVDS RSVD
A75 LVDS_A2+ LVDS RSVD
A76 LVDS_A2- LVDS RSVD
A77 LVDS_VDD_EN LVDS RSVD
A78 LVDS_A3+ LVDS RSVD
A79 LVDS_A3- LVDS RSVD
A80 GND PWR GND
A81 LVDS_A_CK+ LVDS RSVD
A82 LVDS_A_CK- LVDS RSVD
A83 LVDS_I2C_CK LVDS RSVD
A84 LVDS_I2C_DAT LVDS RSVD
A85 GPI3/SD_DATA3 GPIO/SDIO I/O-3.3 SD_DATA3
A86 RSVD19 Local Bus O-3.3 LA18
A87 RSVD19 Local Bus O-3.3 LA17
A88 SERDES_CK_REF1+ SERDES O-3.3 SERDES_CK_REF+
A89 SERDES_CK_REF1- SERDES O-3.3 SERDES_CK_REF-
A90 GND PWR GND
A91 SPI_POWER SPI O-3.3 3.3V Source for carrier SPI flash
A92 SPI_MISO SPI I-3.3 SPI_MISO
A93 GPO0/SD_CLK GPIO/SDIO O-3.3 SD_CLK
A94 SPI_CLK SPI SPI_CLK
A95 SPI_MOSI SPI O-3.3 SPI_MOSI
A96 TPM_PP BOARD CTRL GND
A97 T YPE10# T YPE Single 4K7 pull down, DNI
A98 SER0_TX UART O-3.3 U0_TXD
A99 SER0_RX UART I-3.3 U0_RXD
A100 GND PWR GND
A101 SER1_TX UART O-3.3 U1_TXD
A102 SER1_RX UART I-3.3 U1_RXD
A103 LID# BOARD CTRL N/C
A104 VCC_12V PWR VCC_12V
A105 VCC_12V PWR VCC_12V
A106 VCC_12V PWR VCC_12V
A107 VCC_12V PWR VCC_12V
A108 VCC_12V PWR VCC_12V
A109 VCC_12V PWR VCC_12V
A110 GND PWR GND
Table 2-1: Connector J1 Row A Pinout (Continued)
PIN SIGNAL
SIGNAL
GROUP
TYPE TERMINATION COMMENT
