COMe-P2020 User Guide
28
C49 IRQ1# IRQ Undef ined
C50 IRQ2# IRQ Undef ined
C51 GND PWR GND
C52 SERDES_RX8+ SERDES N/C
C53 SERDES_RX8- SERDES N/C
C54 T YPE0# T YPE Single 4K7 pull down, DNI
C55 SERDES_RX9+ SERDES N/C
C56 SERDES_RX9- SERDES N/C
C57 T YPE1# T YPE Single 4K7 pull down, DNI
C58 SERDES_RX10+ SERDES DP-I MUX_PCIE_RX2_P
C59 SERDES_RX10- SERDES DP-I MUX_PCIE_RX2_N
C60 GND PWR GND
C61 SERDES_RX11+ SERDES DP-I MUX_PCIE_RX3_P
C62 SERDES_RX11- SERDES DP-I MUX_PCIE_RX3_N
C63 RSVD19 Local Bus O-3.3 LA25
C64 RSVD19 Local Bus O-3.3 LA24
C65 SERDES_RX12+ SERDES N/C
C66 SERDES_RX12- SERDES N/C
C67 RSVD19 Local Bus O-3.3 LA23
C68 SERDES_RX13+ SERDES N/C
C69 SERDES_RX13- SERDES N/C
C70 GND PWR GND
C71 SERDES_RX14+ SERDES N/C
C72 SERDES_RX14- SERDES N/C
C73 GND PWR GND
C74 SERDES_RX15+ SERDES N/C
C75 SERDES_RX15- SERDES N/C
C76 GND PWR GND
C77 RSVD19 Local Bus O-3.3 LA22
C78 SERDES_RX16+ SERDES N/C
C79 SERDES_RX16- SERDES N/C
C80 GND PWR GND
C81 SERDES_RX17+ SERDES N/C
C82 SERDES_RX17- SERDES N/C
C83 RSVD19 Local Bus O-3.3 LA21
C84 GND PWR GND
C85 SERDES_RX18+ SERDES N/C
C86 SERDES_RX18- SERDES N/C
C87 GND PWR GND
C88 SERDES_RX19+ SERDES N/C
C89 SERDES_RX19- SERDES N/C
C90 GND PWR GND
C91 SERDES_RX20+ SERDES N/C
C92 SERDES_RX20- SERDES N/C
C93 GND PWR GND
C94 SERDES_RX21+ SERDES N/C
C95 SERDES_RX21- SERDES N/C
C96 GND PWR GND
Table 2-3: Connector J2 Row C Pinout (Continued)
PIN SIGNAL
SIGNAL
GROUP
TYPE TERMINATION COMMENT
