COMe-P2020 User Guide
85
Table 6-6: sconf Command
sconf Provides functions for configuration of external interfaces
SYNTAX: sconf info|select |set [ ]|clear|save|undo|raw
sconf command
info option:
displays available configurations
select option:
selects base configuration
parameter: decimal
<0, 1, ... 8>
number of base configuration
set option:
indicate or configure parameter for new base configuration
parameter: ascii string
parameter for new base configuration
parameter: ascii string
value assigned to
clear option:
clear user config settings in glue logic and reboot
save option:
saves the current settings
undo option:
undo current changes not yet saved
DESCRIPTION: This command is used to configure external interfaces available on the COMe-cP2020’s connectors.
The “sconf info” command shows the possible configurations as well as the currently selected
configuration.
The active configuration is indicated by ‘**’ characters in the “sconf info” output messages.
To configure external interfaces, select a base configuration via the “sconf select” command. Then, the
parameters can be defined more exactly by the “sconf set ” subcommands.
To apply the configuration, invoke the “sconf save” command. After having updated the configuration in
the glue logic, a module powercycle is performed automatically (a hardware reset is not sufficient to
activate the new configuration).
