COMe-P2020 User Guide
42
320h-321h Scratchpad Registers 0-1
322h-327h Scratchpad Registers 2-7 (not implemented)
328h-32Fh Reserved
330h Power Status Register
331h-337h Reserved
338h CPU Status Register
339h CPU Control Register
33Ah Board Variant Register
33Bh-34Fh Reserved
350h PCIe Status Register
351h PCIe Control/Status Register
352h-36Fh Reserved
370h Carrier Interrupt Direction Register
371h-373h Reserved
374h Carrier Interrupt Mode 1 Register
375h Carrier Interrupt Mode 2 Register
376h Board Interrupt Pending Register 1
377h Board Interrupt Pending Register 2
378h Board Interrupt Pending Register 3
379h Board Interrupt Pending Register 4
37Ah Board Interrupt Enable Register 1
37Bh Board Interrupt Enable Register 2
37Ch Board Interrupt Enable Register 3
37Dh Board Interrupt Enable Register 4
37Eh-37Fh Reserved
380h Interrupt Multiplexer Register 1
381h Interrupt MultiplexerRegister 2
382h-38Fh Reserved
390h Carrier Control Register ((Test only!)
Table 3-3: I/O Address Map (Continued)
ADDRESS FUNCTION
