Table 3-42:
0x303: Default Boot Configuration Register
ACTION
D7
D6
D5
D4
D3
D2
D1
D0
READ
NU
NU
NU
NU
NU
NU
cfg_cpu0/1_boot
WRITE
NU
NU
NU
NU
NU
NU
NU
POWER UP
1
1
1
1
1
1
1
1
BITFIELD
DESCRIPTION
[D0-D1]
00
CPU boot holdoff mode for both cores. The e500 cores are prevented
from booting until conf igured by an external master.
01
e500 core 1 is allowed to boot without waiting for conf iguration by an
external master, while e500 core 0 is prevented from booting until
configured by an external master or the other core.
10
e500 core 0 is allowed to boot without waiting for conf iguration by an
external master, while e500 core 1 is prevented from booting until
configured by an external master or the other core.
11
Both e500 cores are allowed to boot without waiting for configuration by
an external master.
Table 3-43:
0x304: Default Boot ROM Location Configuration Register
ACTION
D7
D6
D5
D4
D3
D2
D1
D0
READ
NU
NU
NU
NU
NU
NU
cfg_boot_seq[0:1]
WRITE
NU
NU
NU
NU
NU
NU
NU
POWER UP
1
1
1
1
1
1
1
1
BITFIELD
DESCRIPTION
[D0-D1]
00
Reserved
01
Normal I2C addressing mode is used. Boot sequencer is enabled and
loads configuration information from a ROM on the I2C1 interface. A
valid ROM must be present.
10
Extended I2C addressing mode is used. Boot sequencer is enabled
and loads configuration information from a ROM on the I2C1 interface.
A valid ROM must be present.
11
Boot sequencer is disabled. No I2C ROM is accessed.
Table 3-44:
0x305: Default SerDes Reference Clock Configuration Register
ACTION
D7
D6
D5
D4
D3
D2
D1
D0
READ
NU
NU
NU
NU
NU
NU
NU
cfg_srds_refclk
WRITE
NU
NU
NU
NU
NU
NU
NU
NU
POWER UP
1
1
1
1
1
1
1
1
BITFIELD
DESCRIPTION
[D0]
0
SerDes expects a 125 MHz reference clock frequency.
1
SerDes expects a 100 MHz reference clock frequency.
