COMe-P2020 User Guide
70
Register is currently read only, read value is always 0x00.
Table 3-68: 0x378: Board Interrupt Pending Register 3
ACTION D7 D6 D5 D4 D3 D2 D1 D0
READ 0 0 0 0 0 0 0 Int0
WRITE NU NU NU NU NU NU NU w1c
POWER UP 0 0 0 0 0 0 0 0
BITFIELD DESCRIPTION
[D0] Int0 Interrupt occurred, triggered by WATCHDOG line. Register is cleared by write to '1':
'0' = no Interrupt
'1' = Interrupt is active
Table 3-69: 0x379: Board Interrupt Pending Register 4
ACTION D7 D6 D5 D4 D3 D2 D1 D0
READ 0 0 0 0 0 0 0 0
WRITE NU NU NU NU NU NU NU NU
POWER UP 0 0 0 0 0 0 0 0
Table 3-70: 0x37A: Board Interrupt Enable Register 1
ACTION D7 D6 D5 D4 D3 D2 D1 D0
READ 0 0 0 En4 En3 En2 En1 En0
WRITE NU NU NU En4 En3 En2 En1 En0
POWER UP 0 0 0 0 0 0 0 0
BITFIELD DESCRIPTION
[D0] En0 Enable bit for CON_IRQ[1]# Interrupt Request Register:
'0' = no Interrupt
'1' = Interrupt is active
[D1] En1 Enable bit for CON_IRQ[2]# Interrupt Request Register:
'0' = no Interrupt
'1' = Interrupt is active
[D2] En2 Enable bit for CON_IRQ[3]# Interrupt Request Register:
'0' = no Interrupt
'1' = Interrupt is active
[D3] En3 Enable bit for CON_IRQ[4]# Interrupt Request Register:
'0' = no Interrupt
'1' = Interrupt is active
[D4] En4 Enable bit for CON_IRQ[5]# Interrupt Request Register:
'0' = no Interrupt
'1' = Interrupt is active
