Final Assembly
Be sure that you removed the paint from around the bottom cover
holes (see Figure 25).
Three self-adhesive feet are supplied for the bottom cover. Three
feet provide excellent stability on uneven surfaces. Position the feet on
the bottom as shown in Figure 27.
Figure 27. Installing Feet.
Place the serial number label inside the top cover as shown in
Figure 28. Note: The label is placed on the inside to protect it during
field operation. You can easily check the serial number when
necessary by removing two thumb screws and pulling open the bottom
cover.
Figure 28. Installing Serial Number Label.
