EFCO 433 Series - Manual (Page 88)

June 2012 PART NO. Y017 Page 88 of 90
Series 433 Triple Set Installation Instructions
SECTION IX: Glazing
(Includes Offset and Center-Set Glazing)
[FIG. 119]
Step 14) Door Transom Glazing
Variations in transom glazing are available to match the sidelite glazing configurations
or can be placed in line with the door plane for continuity of the system face. See
Figures 119 and 120 below for specific transom glazing installation.
SCREW SPLINE
JAMBS SIMILAR
8373
9227/9234
8377
8378
8377
9
123
912
3
837
8
837
7
8378
837
8
837
7
2556
8
378
837
7
2556
HN38
HN38
STT6
HN32
STT6 STT6
8373
HN92 HN92
9209 8374
437
6
STT6
STT6
STT6
4 15/32"
437
6
9208 9208
1 3/16"
1 3/16"
1/64"
2556
2 11/32"
1/64"
7/16"
27/64"
27/64"
2 11/32"
[FIG. 120]
HORIZONTAL CUT LENGTH =
TRANSOM OPENING WIDTH
VERTICAL CUT LENGTH =
TRANSOM OPENING HEIGHT
OR
VERTICAL CUT LENGTH =
TRANSOM OPENING
HEIGHT - APPLIED STOP
HEIGHT
(When applied horizontal stops
are used.)
