4.5.2.A Programming a Transaction Dump Code
1. Place the prox.pad plus unit in Program mode.
Press:
99 # Master Code * (default is 1234)
A slow blinking yellow LED indicates that the unit
is in Program mode. A steady yellow LED, in
contrast, means that errors were detected during
programming. Error states can be cleared by press-
ing the asterisk * key.
2. For a LOG DUMP USER (Code Only), press:
50 # 2 # user location # code * code *
For a CARD DUMP, press:
50 # 2 # user location # **
and then present the card at the proximity reader.
(NOTE: A Log Dump User can also be a “card
AND Code” or “Card OR Code” user.)
3. Press * to exit Program mode.
NOTE: Entering the programmed dump code or card
again subsequently causes the unit to send a Transac-
tion Log to the optional PDA DCD program.
4.5.2.B Printing a Transaction Log Manually
1. Place the prox.pad plus unit in Program mode.
Press:
99 # Master Code * (default is 1234)
A slow blinking yellow LED indicates that the unit
is in Program mode. A steady yellow LED, in
contrast, means that errors were detected during
programming. Error states can be cleared by press-
ing the asterisk * key.
2. Hold the PDA up to the prox.pad plus IR port
steadily (about one or two inches away; the IR
port is located to the right of the yellow LED) and
then press:
70 # 0 # 0 # **
