Detex DTX-4300 User Manual
Page 24
Table 2-2. IEI-Supplied Parts/Optional Items
Quantity
Description
1
Keypad/control unit assembly, with Prox Sensor, Backplate,
hex socket screw
1
Filler Piece/REX Button
1
Press to Exit Label
4
Wall Anchors
4
Mounting Screws
1
Antenna Backplate for remote mounting
1
Silicone Rubber “dogbone”
4
Self-Adhering Pads (for glass mounting)
1
Installer Guide
1
CD-ROM containing instruction manuals
4
Cable Assemblies
1
Tamper Screw
Optional Items
1
Replacement Battery: Panasonic BR1225 or equivalent
lots of 25 only
ProxKey Keytags (IEI part number 0297301)
lots of 25 only
ProxCard II Cards (IEI part number 0297401)
1
Hub Manager
TM
Professional PC Software (version 5 or
higher)
1
IEI Data Collection Device (DCD) PDA Software
Chapter 2: Installation
2.3 Checking the Cables
2-6
prox.pad plus Install/Program. Manual, PPP, D4b
Part No. 6105679, Rev. 1.1
