Detex V50 EE - Manual

FOR SPECIAL LOCKING ARRANGEMENT:
THIS PRODUCT MUST BE CONNECTED INTO A FIRE ALARM SYSTEM PER NFPA CODE OR OTHER
REGULATIONS SO THAT, IN THE EVENT OF FIRE, THE TIME DELAY WILL BE BYPASSED. CONTACT
YOUR LOCAL CODE AUTHORITY TO VERIFY COMPLIANCE WITH FIRE AND BUILDING CODES.
THE DELAYED EGRESS DEVICE SHOULD BE ROUTINELY CHECKED FOR PROPER OPERATION AND
COMPLIANCE WITH FIRE AND BUILDING CODES
Owner's Copy
Mortise cylinder not included with device.
Standard Yale type cam required.
U.S. PATENT NUMBERS:
6009732
6205825B1
6532777B2
INTERNATIONAL PATENT NUMBER:
PCT6009732
TRO - TOP ROD ONLY INSTALLATION
V51 and FV51 SERIES
TOP AND BOTTOM ROD
INSTALLATION
V50 and FV50 SERIES
SURFACE VERTICAL
ROD INSTALLATION
Detex Corporation, 302 Detex Drive, New Braunfels, Texas 78130-3045
(830)629-2900 / 1-800-729-3839 / Fax (830)620-6711
E-MAIL: [email protected] INTERNET: www.detex.com
104832 June 27, 2011
INSTALLATION INSTRUCTIONS FOR
VALUE SERIES® SURFACE VERTICAL ROD V50/V51 SERIES AND FV50/FV51 SERIES
FV50 / V50 x EE
FV51 / V51 x EE
Delayed Egress
L9 = Less 9v Battery
SI = Status Indicator "ON"
* Narrow Stile "NS" option
104832 Page 1
