11-8 IP Router - Release 1.8
Router Configuration
Internet Connection using NAT and Static NAT Addresses
216.174.44.232 is the static NAT address assigned to the router.
216.174.44.233 is the static NAT address assigned to the controller.
216.174.44.234 is the static NAT address for a server*.
216.174.44.235 is the static NAT address for a host*.
*In the private network that can be reached from the outside world.
There can be up to 16 static NAT addresses, therefore the actual range can be
216.174.44.232 to 216.174.44.247. Only 4 were used in this example.
Command Description
add 1 "wan1" static ip network
0.0.0.0 0.0.0.0 1
Adds a static IP network (route) to the WAN
interface
add 1 "wan1" static nat address
192.168.21.14 216.174.44.232
Add static NAT bi-directional mapping to wan1
add 1 "wan1" static nat address
192.168.21.15 216.174.44.233
Add static NAT bi-directional mapping to wan1
add 1 "wan1" static nat address
192.168.21.16 216.174.44.234
Add static NAT bi-directional mapping to wan1
add 1 "wan1" static nat address
192.168.21.17 216.174.44.235
Add static NAT bi-directional mapping to wan1
set 1:1:1 encapsulation fr Set the encapsulation on trunk 1 to Frame Relay
set 1 lmi annexd Disable LMI Annex D
set 1 "wan1" trunk 1 Set the WAN interface named "wan1" to be
mapped to trunk 1
set 1 "wan1" dlci 101 Set the DLCI number
reset 1 Reboot the router, to enable all configurations set
