IP Router - Release 1.8 11-7
Router Configuration
Internet Connection using NAT and Static NAT Addresses
Internet Connection using NAT and Static NAT
Addresses
Router in Slot 1
ISP Router that provides the Internet connection. Router with NAT and Static NAT
addresses.
Command Description
set clock1 a:1 Set primary master transmit clock source
set 1 default Set Router to default settings
disconnect a:1 Disconnect all connections to the T1 on the
Controller (slot a)
disconnect 1 Disconnect all connections to the router in slot 1
set a:1:all type data Set the T1-1 of the Controller, Type to Data
connect a:1:all 1:1:1 Connect all of T1-1 to the Router that is in slot 1
rename 1 "LocalUnit" "Boulder" Rename the Adit 600 from "LocalUnit" (default)
to "Boulder" (LAN)
rename 1 "RemoteUnit" "wan1" Rename WAN #1 from "RemoteUnit" (default) to
"wan1"
set ethernet ip address
192.168.21.15 255.255.255.0
Set the Ethernet IP address and Subnet Mask, for
the Adit 600
set ip gateway 192.168.21.14 Set the IP gateway (default route), for the Adit
600
set 1:1 ip address 192.168.21.14
255.255.255.0
Set the Ethernet IP address, in the conventional IP
address format. (Router LAN)
set 1 "wan1" nat enable Set the WAN interface named "wan1" enable
NAT mapping
set 1 "wan1" nat port dynamic Set the WAN interface named "wan1" to set NAT
port mapping to be dynamic
set 1 "wan1" nat address
216.174.44.2 1
Set the WAN interface named "wan1" NAT
address
