4-16
IP Router - Release 1.8
Profile Directory: Local Profile
Static Addresses
Static Addresses
Use this screen to define static addresses that are based on the Ethernet MAC or IP
Address of a specific device on the local LAN. Typically, the Router would learn of
these devices by monitoring LAN/WAN packets. By defining a static address, you are
telling the Router the location of the corresponding device before the Router learns
where this device resides. Static addresses are typically used in a bridging situation.
Use the Local (LAN) Profile to define static addresses for devices that are located on
the LAN. If you wish to establish static addresses for devices on remote LAN’s, access
this screen using the corresponding Remote Profile.
NOTE: Each static address filter will count toward the maximum number of
500 filters.
1. Select Configuration
[E
NTER
].
2. Select LAN
NTER
].
Profile
Directory
Window
