IP Router - Release 1.8 7-11
Verification Window
Port Monitor
The following an example of a WAN Monitor trace.
>>>Sending>>> Time= 2:55:31 msg-0001 WAN-WAN+2 14 octets (ESC to stop)
00: 00 01 03 08 00 75 95 01 01 00 03 02 67 66
FR DLCI-0 Bridged Eth
<<
00: 00 01 03 08 00 7D 95 01 01 00 03 02 67 67 07 03
10: 06 A0 82
FR DLCI-0 Bridged Eth
<<
00: 18 41 03 CC 45 00 00 60 E5 1F 00 00 7F 11 81 AA
10: 14 14 00 03 C0 A8 00 04 00 89 00 89 00 4C 48 0F
FR DLCI-100 IP
IP4-HDR: src=20.20.0.3 dst=192.168.0.4 ttl=127 len=20
UDP-HDR: Ports src=137 dst=137 len=76 cksum is=480F,cacl=0
>>>Sending>>> Time= 2:55:38 msg-0004 WAN-WAN+2 100 octets (ESC to stop)
00: 18 41 03 CC 45 00 00 60 E5 1F 00 00 7E 11 82 AA
10: 14 14 00 03 C0 A8 00 04 00 89 00 89 00 4C 48 0F
FR DLCI-100 IP
IP4-HDR: src=20.20.0.3 dst=192.168.0.4 ttl=126 len=20
UDP-HDR: Ports src=137 dst=137 len=76 cksum is=480F,cacl=0
