Flash Download Screen
2H22-08R SmartSwitch 2208 User’s Guide Page 5-53
To access the Flash Download screen from the Device Specific
Configuration Menu screen, use the arrow keys to highlight the FLASH
DOWNLOAD menu item and press ENTER. The Flash Download screen
displays.
Figure 5-21 Flash Download Screen
NOTE
Download Server IP and Download Server File Name displays
only when TFTP or RUNTIME are selected in Download
Method.
Firmware Revision: XX.XX.XX
Flash Download
Download Method:
Reboot After Download:
TFTP Gateway IP Addr:
Last Image Server IP:
Last Image File Name:
Download Server IP:
Download File Name:
2159-24
BOOTPROM Revision: XX.XX.XX
[TFTP]
[YES]
134.141.79.123
134.141.79.121
/tftpboot/2H22.hex
134.141.79.121
/tftpboot/2H22.hex
Device Type: 2H22-08R
EXIT RETURN
2H22-08R LOCAL MANAGEMENT
TFTP DOWNLOAD. WILL COMMIT TO FLASH. REBOOT IN PROGRESS...
EXECUTE
