Dell XPS/Dimension XPS User Manual
Page 122

122
Appendix
www
.dell.com | support.dell.com
Connectors
External connectors:
Serial
two 9-pin connectors; 16550C-
compatible
Parallel
25-hole connector (bidirectional)
Network adapter
10/100/1000 Ethernet connector
PS/2 (keyboard and mouse)
6-pin mini-DIN
USB
two front-panel and six back-panel USB
2.0–compliant connectors
headphones
one front-panel connector
System board connectors:
Primary IDE drive
40-pin connector
Secondary IDE drive
40-pin connector
Floppy drive
34-pin connector
Fans (3)
3-pin connector
I/O Panel
34-pin connector
Serial ATA (2)
7-pin connector
Controls and Lights
Power control
push button
Power light
green light on power button—blinking
green in sleep state; solid green for
power-on state
Hard-drive access light
green
Link integrity light (on integrated
network adapter)
green light for 10-Mb operation; orange
light for 100-Mb operation
Activity light (on integrated network
adapter)
yellow blinking light
Diagnostic lights
four lights on the back panel
G0550bk1.book Page 122 Thursday, July 10, 2003 1:55 PM
